SAKO SUNPOLO 6 KW Hybrid MPPT Solar Inverter
Powerful 6 kW hybrid solar inverter with built-in 120 A MPPT + BMS, wide PV input range (120–500 VDC), dual AC & 12 V outputs, and optional battery-free operation — ideal for homes, villas, offices or small commercial setups.
SAKO SUNPOLO 6 KW Hybrid Solar Inverter
Cable City ke solar solutions range ka high-capacity option
The SUNPOLO 6 KW inverter delivers a robust, flexible and efficient solar power solution — perfect for residential houses, villas, offices, and small business setups needing reliable power with solar + battery or even direct solar (battery-free) operation.
Key features include a built-in 120 A MPPT solar charger with support for large solar arrays (up to 6 kW PV input), integrated smart BMS (compatible with lithium batteries) for battery safety and longevity, and support for on-grid, off-grid, or hybrid operation. The inverter supports dual AC outputs + 12 V DC output, giving flexibility to power multiple circuits and small DC loads simultaneously.
Users can also take advantage of built-in WiFi / RS232 / RS485 / USB communication ports, enabling system monitoring, remote control, and integration with battery management or smart solar setups.
More, the inverter can work even without battery during day time — making it cost-effective for setups where battery backup is not mandatory.
SUNPOLO 6 KW also offers parallel operation — up to 9 units can be connected together for higher capacity installations, ideal for large homes, commercial buildings or small industries.
With pure sine wave output, robust surge handling, and efficient DC-to-AC conversion (up to 96 %), it ensures safe and stable power supply for appliances, electronics, and heavy loads.
Key Specifications
| Parameter / Feature | Specification / Detail |
|---|---|
| Max PV Input Power | 6000 W (6 kW) |
| Rated AC Output Power | 6000 W (6 kW) |
| PV Input (DC) | Nominal 360 VDC / Max 500 VDC |
| MPPT Voltage Range | 120 – 450 VDC |
| MPPT / Max Input Current | 1 tracker / 27 A |
| Solar Charger & AC Charge Current | 120 A (built-in) |
| Output Voltage (AC) | 230 VAC, single-phase |
| Output Voltage Range | 184–265 VAC (or selectable 195–253 VAC) |
| Nominal Output Current (AC) | ~ 26.0 A |
| Output Waveform | Pure sine wave |
| Efficiency (DC → AC) | Up to 96 % |
| Battery Support | Works with or without battery — supports Lead-acid & LiFePO₄ / Lithium batteries via built-in BMS |
| Outputs | Dual AC outputs + 12 V DC output (10A) |
| Parallel Operation | Up to 9 units (for larger setups) |
| Communication / Monitoring | RS232, RS485, USB, Optional WiFi / Dry Contact / BMS interface |
| Build & Interface | LCD + Touch Buttons, RGB status LED ring for operation modes |
| Physical Specs | Dimensions 456 × 303 × 148 mm; Weight ~12 kg |
| Environment / Operation Range | Humidity 5–95% (non-condensing), Operating Temp –10 °C to +50 °C |
